FV-200PP Pre-Amplifier Mixer Panel
Original price was: ฿18,000.00.฿15,023.00Current price is: ฿15,023.00.
รายละเอียดสินค้า
FV-200PP Pre-Amplifier Mixer Panel
เป็นพรีแอมพปลิไฟเออร์ที่ถูกออกแบบมาให้ใช้งานในระบบประกาศฉุกเฉิน
Power Source Usable Power Supply Unit: FV-200PS
24 V DC (operating range: 19.5 – 27 V DC), M3 screw terminal
Current Consumption 110 mA
Audio Input
EV: -20 dB*, 600Ω, unbalanced, removable terminal block (2pins)
Timer : -20 dB*, 600 Ω,unbalanced,removable terminal block (2 pins)
Paging : -60/-20 dB* (selectable), 600 Ω, balanced, removable terminal block (3pins)
RF Link : 0 dB*, 600 Ω,unbalanced,removable terminal block (2 pins)
MIC/LINE 1 – 4 : -60/-20 dB* (selectable), 600 Ω, balanced, removable terminal block (3pins)
AUX 1 – 2 : -20 dB*,10 kΩ, unbalanced, RCA Jack
Audio Output Priority output : 0 dB*, balanced, removable terminal block (3 pins)
BGM output : 0 dB*, balanced, Removable terminal block (3 pins)
Control Input
Timer : No-voltage make contact input, open voltage : 24 V DC,
short-circuit current : Under 5 mA, removable terminal block (2 pins)
Paging : No-voltage make contact input, open voltage : 24 V DC,
short-circuit current : Under 5 mA, removable terminal block (2 pins)
EV : No-voltage make contact input, open voltage : 24 V DC,
short-circuit current : Under 5 mA, removable terminal block (2 pins)
Control Output All Call : Contact Switch (Normally Open), removable terminal block (2 pins)
Frequency Response 50 Hz – 15 kHz, ±3 dB, 1 kHz
Muting MIC/LINE 1 : Mutes other input signals (Mic/Line 2 – 4, AUX 1 – 2) by 0 – 30 dB attenuation
Phantom Power MIC/LINE 1 (selectable) (+21 V DC)
Priority Control Fireman’s microphone > EV > Timer > Paging > Remote microphone > Mic / Line 1 > Mic / Line 2 – 4 & AUX 1 – 2
Tone Control
Bass : -10 dB at 100 Hz, +10 dB at 100 Hz (for INPUT BGM)
Treble : -10 dB at 10 kHz, +10 dB at 10 kHz (for INPUT BGM)
S/N Ratio Over 60 dB
Distortion Under 1% (1 kHz, rated output)
LED Indicator Power (Green)
Operating Temperature 0 ℃ to +40 ℃
Operating Humidity Under 90% RH (no condensation)
Finish Front Panel : Aluminum, black, alumite
Dimensions 482 (W) × 88.4 (H) × 353.3 (D) mm
Weight 4.2 kg
Accessory Removable terminal plug (2 pins) x 7, removable terminal plug (3 pins) x 8, Instruction Manual x 1
